TWK-IIIA Hole Cutting Tool
   User’s Manual
   Familiar yourself with this Manual prior to operation


Tuwei Construction Equipment Manufacturing Co., Ltd, Huangyan, Taizhou
The People’s Republic of China

Table of Contents

I.              Major purposes and application scope

This machine is applicable for tapping of various seamless steel tubing, galvanized pipes, plastic-lining pipes etc, to facilitate the mounting of pipes. It’s an ideal tool for construction industry and pipeline construction sectors.

II.             Technological Parameters

Max. diameter of hole to be tapped ……………………………………………………114mm
Max. wall thickness of hole to be tapped…………………………………..……………10mm
RPM of spindle (work coupling with 1400 rpm reduction motor)……………………120rpm
Electric motor …………………………………………...…………………………………700 W
Overall dimensions ( WxDxH) …………………………...………340mm✕340mm✕620mm
Net weight……………………………………………………………………………..….…19kgs

III.           Precautions

You are required to read this manual in detail to familiar yourself with functions of machine.
Earthing and fuse are required in the circuit. Never run the machine overload.

IV.          Driving System

In this machine, the tapping saw is directly driven by a reduction motor, resulting in a reduced loss of mechanic power. The feeding movement is realized by manual rack and pinion system.

V.           Electric System

The Electric System of this Machine consists of an electric motor, a switch and cables. The stop/start of the machine is controlled by the switch. An electric motor is the only load. The power supply shall agree with the requirements of motor: three phase, 380 V, 50 Hz. Sound earthing of ground wire (black) is required prior to starting the machine.

VI.          Operation and Adjustment

Put the machine on the steel tubing to be tapped and let the V-shaped surface at the bottom touch the tubing (Refer to Fig. 1). Let the machine run idle to check whether it’s normal (Observe the rotating direction).Turn the feed lever slowly. First tap a location hole with center bit. Then tap the hole to its size. Add coolant to the saw during operation to extend its service life significantly.
VII.         Maintenance
Be gentle in operation. After operation, apply anti-rusty oil to the surface of slide after cleaning it. Add lubrication grease to all the joints of moving units. Never operate the machine overload.










1.    Our company reserves the authority of changing the products and specification, if any alteration we don't inform specially.

2.    Difference between the picture and the object, please be subject to the object.
